| Specification： | T B | TH500 - NQ - II |
| Shieding Gas： | 80%Ar + 20%CO2 | |
TB TH500-NQ-II - Characteristics
( 1 ) The product is 500MPa weathering resistant steel welding wire.
( 2 ) The molten metal contains Cu,Ni and Cr，weathering resistant is well.
( 3 ) It’s used to weld 500MPa weathering resistant steel，such as bridges, buildings, vehicles, etc.
TB TH500-NQ-II - Precautions
( 1 ) Adequately clear the oil,rust,moisture,dust and other debris of the welded parts.
( 2 ) It’s used to weld Thick plate welding (25 mm above) or large binding
place, preheat in 90~120℃ before welding.
One chemical composition of the weld metal sample (wt%)
| C | Si | Mn | P | S | Cu | Ni | Cr |
| 0.07 | 0.50 | 1.10 | 0.012 | 0.008 | 0.30 | 0.30 | 0.35 |
One mechanical properties of the weld metal sample
| Tensild Strength MPa | Yield Strength MPa | Elongation % | Impact Value | |
| ℃ | J | |||
| 550 | 460 | 28 | -40 | 100 |
The specifications of the product and welding condition (DC+)：
| Dia (mm) Welding Condition | 1.0 | 1.2 | 1.4 | 1.6 | |
| Short Circuiting Transfer | Current A | 80 ~ 160 | 100 ~ 210 | - | - |
| Voltage V | 16 ~ 22 | 17 ~ 22 | - | - | |
| Spray Transfer | Current A | 180 ~ 280 | 200 ~ 300 | 210 ~ 320 | 220 ~ 330 |
| Voltage V | 24 ~ 30 | 24 ~ 30 | 24 ~ 32 | 24 ~ 32 | |
